100kVar Fuseless Shunt High Voltage Power Capacitor

herong electric
Contact Now

100kVar Fuseless Shunt High Voltage Power Capacitor

  • 1
  • 2

Brand Name : HERONG ELECTRIC

Model Number : BAM6.6-100-1W

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1PC

Price : Negotiable

Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram

Supply Ability : 2000000KVAR/YEAR

Delivery Time : 30 work days

Packaging Details : Export standard packing

Rated frequency : 50Hz;60Hz

Protection method : Fuseless

Number of phases : single-phase

Capacitance deviation : -3%~+3%

Package : Export standard packing

Material : Stainless Steel

Capacity : 100kvar

Contact Now

High Voltage Shunt Power Capacitor BAM6.6-100-1W, High Voltage Capacitor





Function of High Voltage Shunt Power Capacitor BAM6.6-100-1W, High Voltage Capacitor Bank

Rated voltage

11KV

Special specifications can be negotiated .

Rated frequency 50Hz;60Hz
Rated Capacity 100 kvar
Insulation level 38/95kV
Protection method
Fuseless
Number of phases single-phase
Capacitance deviation -3%~+5%
Package Export  packing
Loss tangent value (tanδ) ≤0.0002
Discharge resistance The capacitor is equipped with a discharging resistor. After being disconnected from the grid, the voltage on the terminal can drop below 50V within 5 minutes



Main features of High Voltage Shunt Power Capacitor BAM6.6-100-1W,High Voltage Capacitor Bank

1. Capacitor made of shell and core, shell body constructed of thick steel sheet being soldiered. Outgoing porcelain bushing welded and passed through
top cover of capacitor, two sides of shell provided with two lifting brackets, one of lifting bracket assembled with earthing bolt.
2. Capacitor core has several elements and insulated parts to be stacked. It uses Polypropylene film as medium and Al foil as polar plate to be rolled.
3. In order to work in different voltage rating, the elements in core will be connected in series or parallel. As required, the discharging resistance can be built-in.



Overview of High Voltage Shunt Power Capacitor BAM6.6-100-1W, High Voltage Capacitor Bank

High voltage shunt capacitor (Power capacitor) is mainly used in the A.C,Power system with 50Hz or 60Hz to improve power factor, reduce reactive power loss, mend voltage quality, plenitude elaborate generate power' equipment and supply power equipment efficiency, it is national recommend save power products.



Working Conditions of High Voltage Shunt Power Capacitor BAM6.6-100-1W,High Voltage Capacitor

  • 5.1 Applicable for indoor and outdoor
  • 5.2 The altitude of the installation site generally does not exceed 2000 meters
  • 5.3 Temperature category: -40/D
  • 5.4 There is no gas or steam that is severely corrosive to metals.
  • 5.5 No strong mechanical vibration
